SRL-W
Chenxing
Product Description
The SRL-W Series Heating/Cooling Mixer Unit is a fully integrated system designed for mixing, stirring, drying, and coloring plastic materials, especially PVC compounds. Featuring a horizontal structure, this unit provides larger capacity, stable operation, and superior mixing performance, making it ideal for industrial-scale production.
It is widely used in plastic sheet, pipe, profile, and biodegradable material production lines, delivering consistent quality and improved efficiency.
Combines heating and cooling systems into one unit, ensuring seamless material processing.
Horizontal design allows higher batch volumes compared to vertical systems.
Advanced blade design ensures excellent dispersion and moisture removal.
Equipped with branded electrical components for stable and precise control.
All blades pass dynamic and static balance testing, ensuring long-term operation.
The SRL-W mixer unit is ideal for:
PVC compound production
Plastic sheet & board extrusion
Pipe and profile manufacturing
WPC and biodegradable materials
Recycling and reprocessing lines
The SRL-W system integrates a hot mixer and cooling mixer in a horizontal configuration:
Raw materials are fed into the hot mixer
High-speed blades generate friction heat for rapid mixing and drying
Materials are discharged automatically into the cooling mixer
Cooling stabilizes temperature and prevents material degradation
Finished materials are discharged for storage or further processing
This ensures consistent quality, improved efficiency, and reduced manual handling.
Suitable for mixing, drying, and coloring various plastic materials
Equipped with electric heating and self-friction heating system
Double-channel sealing design prevents leakage
Pneumatic opening system for hot and cold mixer lids
Reliable electrical control system with international components
Stable performance with low energy consumption
| Model | Capacity (L) | Effective Capacity (L) | Main Shaft Speed (rpm) | Motor Power (kW) | Heating Method | Cooling Method | Discharge Method |
|---|---|---|---|---|---|---|---|
| SRL-W200/500 | 200/500 | 140/300 | 950/500 | 42/7.5 | Electric / Self-friction | Water Cooling | Pneumatic |
| SRL-W300/600 | 300/600 | 210/360 | 950/500 | 55/11 | Electric / Self-friction | Water Cooling | Pneumatic |
| SRL-W300/1000 | 300/1000 | 210/600 | 950/500 | 55/11 | Electric / Self-friction | Water Cooling | Pneumatic |
| SRL-W500/1000 | 500/1000 | 350/600 | 860/500 | 75/15 | Electric / Self-friction | Water Cooling | Pneumatic |
| SRL-W500/1600 | 500/1600 | 350/1000 | 860/500 | 75/18.5 | Electric / Self-friction | Water Cooling | Pneumatic |
| SRL-W800/2000 | 800/2000 | 560/1200 | 630/500 | 110/22 | Electric / Self-friction | Water Cooling | Pneumatic |
| SRL-W1000/3000 | 1000/3000 | 700/1800 | 595/500 | 132/30 | Electric / Self-friction | Water Cooling | Pneumatic |
| SRL-W1600/4000 | 1600/4000 | 1120/2400 | 595/500 | 160/45 | Electric / Self-friction | Water Cooling | Pneumatic |
We offer complete customization based on your production requirements:
Voltage: 380V / 415V / 480V / 60Hz
PLC automatic control system
Stainless steel contact parts
Dust removal system integration
Full plant layout & turnkey solution
The SRL-W mixer unit is a core component in plastic production lines, and can be integrated with:
Extrusion lines (pipe, sheet, profile)
Recycling and pelletizing systems
Automatic feeding & storage systems
We provide one-stop turnkey solutions to optimize your entire production process.
A: SRL-W is horizontal and suitable for large-scale production, while SRL-Z is vertical and more space-saving.
A: Mainly PVC, but also suitable for PE, PP, WPC, and biodegradable plastics.
A: Yes, it can be equipped with PLC systems for full automation.
A: Yes, it is designed for stable long-term industrial operation.
A: Yes, we supply full solutions including mixing, extrusion, and recycling systems.
Looking for a reliable and high-capacity plastic mixing system?
Contact us now to get:
Customized solution for your production line
Competitive factory pricing
Professional engineering support
Fast delivery & global service
Send your inquiry today and increase your production efficiency.
