SJSZ80 High-Capacity PVC Pelletizing Line (500kg/h Output)

Mould-Face-Cutting Technology for Uniform Φ3mm Granules

Compact and Portable Pelletizer for Easy Installation

Energy-Efficient Hot-Cutting Process for Plastic Recycling

Industrial Granule Production Line with Minimal Material Waste

Automated Pelletizing System for PVC and Thermoplastics

Share to:

PVC Pelletizing Line | Mould-Face-Cutting System for Industrial Plastic Recycling & Granule Production

Name: PVC Pelletizing Line | Mould-Face-Cutting System for Industrial Plastic Recycling & Granule Production
Brand: Chenxing
Rating: 5.0 (3 reviews)

Availability:

Quantity:



Produce uniform PVC pellets (Φ3mm) with our hot-cutting pelletizing line. Achieve 500kg/h output, low energy consumption, and easy mobility. Ideal for recycling and industrial applications.
Inquire

Model:
SJSZ
Brand:
Chenxing

Product Description

The PVC Pelletizing Line (Mould-Face-Cutting Type) is a high-precision industrial system designed for hot-cutting PVC and other plastics into uniform granules (Φ3mm). With production capacities up to 500kg/h (SJSZ80 model), this line ensures rapid, energy-efficient granulation for recycling and manufacturing. Featuring mould-face-cutting technology, it delivers consistent granule size and minimal material waste, ideal for plastic recycling plants and PVC compound production. Its compact design (12-15m total length) allows easy installation and mobility, while low power consumption (15-55kW) reduces operational costs. Perfect for B2B clients seeking scalable, high-output pelletizing solutions for industrial applications.

Process flow:

Mixer→Spring loader→Conical twin-screw extruder→Mould & Cutter→Air-conveying system→Silo

Features and application

-Saving power: the electrical part adopts advanced frequency conversion technology;

-High effiency: the fast net-changing device may help remove impurities from ganules quickly and effiently;

-Broad application: the conical twin-screw extruder is suitable for various hard PVC & CPVC recipes;

-Zero pollution: all parts of the granules contact are made of stainless steel.

Product Parameters

Extruder model	Screw diameter	Pellet size	Main motor power	Output
SJSZ55	55/110 mm	Φ3-Φ4 mm	22 kw	100-120 kg/h
SJSZ65	65/132 mm	Φ3-Φ4 mm	37 kw	220-260 kg/h
SJSZ80	80/156 mm	Φ3-Φ4 mm	55 kw	320-450 kg/h
SJSZ92	92/188 mm	Φ3-Φ4 mm	110 kw	650-800 kg/h

Detailed Photos

FAQ

FAQs

What materials can this pelletizing line process?

The line is optimized for PVC but also handles other thermoplastics, supporting recycling and compound production.
What is the maximum production capacity?

The SJSZ80 model achieves 500kg/h output, while smaller models (SJSZ65/SJSZ51) offer 250-300kg/h and 100-120kg/h, respectively.
Is the line suitable for mobile recycling operations?

Yes. The compact design (12-15m length) and easy mobility make it ideal for on-site recycling or temporary installations.
Can the line handle post-consumer PVC waste?

Absolutely. It processes recycled PVC flakes into uniform pellets for reuse in manufacturing pipes, profiles, and packaging.
