SRL-Z
Chenxing
Product Description
The SRL-Z Series Vertical Mixing Unit is a high-performance integrated system designed for mixing, drying, and coloring of plastic materials, especially PVC compounds. It combines a high-speed hot mixer and a cooling mixer into a single vertical structure, optimizing workflow efficiency and saving factory space.
This unit is widely used in plastic profile, pipe, sheet, and compounding production lines, delivering stable performance and consistent material quality.
Combines heating, mixing, and cooling in one unit, reducing material handling and improving efficiency.
High-speed mixing generates friction heat for rapid blending and moisture removal.
Compact vertical layout reduces floor space and simplifies plant layout.
Balanced design ensures smooth running and consistent batch quality.
Optimized structure minimizes power consumption and operational noise.
The SRL-Z Vertical Mixing Unit is widely used in:
PVC compound production
Plastic pipe & profile extrusion
Plastic sheet and board manufacturing
Masterbatch production
Plastic recycling and pelletizing
The SRL-Z mixing unit operates through a combined process:
Raw materials enter the high-speed hot mixer
Friction heat rapidly mixes and dries materials
Heated materials are automatically transferred to the cooling mixer
Cooling process stabilizes material temperature
Finished materials are discharged for storage or further processing
This integrated system ensures efficient material preparation and consistent downstream production performance.
| Model | Total Capacity (L) | Effective Capacity (L) | Hot Mixer Power (kW) | Cooling Motor Power (kW) | Heating Method | Discharge Method |
|---|---|---|---|---|---|---|
| SRL-Z50/100 | 50/100 | 35/70 | 11 | 5.5 | Electric | Manual/Pneumatic |
| SRL-Z100/200 | 100/200 | 70/140 | 22 | 7.5 | Electric | Manual/Pneumatic |
| SRL-Z200/500 | 200/500 | 140/350 | 45 | 11 | Electric | Manual/Pneumatic |
| SRL-Z300/600 | 300/600 | 210/420 | 55 | 11 | Electric | Manual/Pneumatic |
| SRL-Z500/1000 | 500/1000 | 350/700 | 75 | 15 | Electric | Manual/Pneumatic |
| SRL-Z800/1600 | 800/1600 | 560/1120 | 110 | 30 | Electric | Manual/Pneumatic |
Suitable for PVC powder mixing, drying, and coloring
High mixing efficiency with uniform material distribution
Double sealing system ensures airtight operation
Cooling mixer with durable cover design to prevent deformation
Passed dynamic and static balance tests for stability
We provide tailored solutions for your factory:
Voltage & frequency customization (380V / 415V / 480V / 60Hz)
PLC automatic control system
Stainless steel material options
Fully automatic feeding & storage system integration
Complete plant layout design
The SRL-Z unit is a turnkey mixing system, ideal for:
PVC compounding plants
Pipe extrusion factories
Recycling pelletizing lines
We offer full production line integration, helping you reduce labor costs and increase productivity.
A: It is mainly used for PVC, but also suitable for other plastic powders such as PE, PP, and additives.
A: It saves factory space and improves workflow efficiency compared to horizontal systems.
A: Yes, it integrates hot mixing and cooling processes in one system.
A: Yes, the machine is designed for stable, long-term industrial operation.
A: Yes, we offer complete solutions including mixing, extrusion, and recycling systems.
Looking to upgrade your plastic mixing efficiency and product consistency?
Contact us now to get:
Customized equipment solution
Competitive factory price
Technical consultation & layout design
Fast delivery & global support
Send your inquiry today and boost your production efficiency.
